نصب Galera Cluster بر روی debian 10

sudo apt update && sudo apt -y upgrade && sudo reboot

# DB1
sudo hostnamectl set-hostname db1.linuxlearn.org --static

# DB2
sudo hostnamectl set-hostname db2.linuxlearn.org --static

# DB3
sudo hostnamectl set-hostname db3.linuxlearn.org --static

sudo tee -a /etc/hosts<<EOF
10.0.0.2 db1.linuxlearn.org db1
10.0.0.3 db2.linuxlearn.org db2
10.0.0.4 db3.linuxlearn.org db3
EOF

sudo apt -y install mariadb-server mariadb-client

$ sudo mysql_secure_installation

NOTE: RUNNING ALL PARTS OF THIS SCRIPT IS RECOMMENDED FOR ALL MariaDB
SERVERS IN PRODUCTION USE! PLEASE READ EACH STEP CAREFULLY!
In order to log into MariaDB to secure it, we'll need the current
password for the root user. If you've just installed MariaDB, and
you haven't set the root password yet, the password will be blank,
so you should just press enter here.
Enter current password for root (enter for none):
OK, successfully used password, moving on...
Setting the root password ensures that nobody can log into the MariaDB
root user without the proper authorisation.
Set root password? [Y/n] y
New password:
Re-enter new password:
Password updated successfully!
Reloading privilege tables..
... Success!
By default, a MariaDB installation has an anonymous user, allowing anyone
to log into MariaDB without having to have a user account created for
them. This is intended only for testing, and to make the installation
go a bit smoother. You should remove them before moving into a
production environment.
Remove anonymous users? [Y/n] y
... Success!
Normally, root should only be allowed to connect from 'localhost'. This
ensures that someone cannot guess at the root password from the network.
Disallow root login remotely? [Y/n] y
... Success!
By default, MariaDB comes with a database named 'test' that anyone can
access. This is also intended only for testing, and should be removed
before moving into a production environment.
Remove test database and access to it? [Y/n] y
- Dropping test database...
... Success!
- Removing privileges on test database...
... Success!
Reloading the privilege tables will ensure that all changes made so far
will take effect immediately.
Reload privilege tables now? [Y/n] y
... Success!
Cleaning up...
All done! If you've completed all of the above steps, your MariaDB
installation should now be secure.
Thanks for using MariaDB!

$ sudo vim /etc/mysql/mariadb.conf.d/50-server.cnf

#bind-address = 127.0.0.1

$ sudo vim /etc/mysql/mariadb.conf.d/50-server.cnf

[galera]
wsrep_on=ON
wsrep_provider=/usr/lib/galera/libgalera_smm.so
wsrep_cluster_address=gcomm://
binlog_format=row
default_storage_engine=InnoDB
innodb_autoinc_lock_mode=2
bind-address=0.0.0.0
wsrep_cluster_name="galera_cluster"
wsrep_node_address="db1"

sudo galera_new_cluster

sudo systemctl restart mariadb

$ sudo vim /etc/mysql/mariadb.conf.d/50-server.cnf

[galera]
wsrep_on=ON
wsrep_provider=/usr/lib/galera/libgalera_smm.so
# Specify cluster nodes
wsrep_cluster_address="gcomm://db1,db2,db3"
binlog_format=row
default_storage_engine=InnoDB
innodb_autoinc_lock_mode=2
bind-address=0.0.0.0
wsrep_cluster_name="galera_cluster"
wsrep_node_address="db2"

sudo systemctl restart mariadb

$ sudo vim /etc/mysql/mariadb.conf.d/50-server.cnf

[galera]
wsrep_on=ON
wsrep_provider=/usr/lib/galera/libgalera_smm.so
# Specify cluster nodes
wsrep_cluster_address="gcomm://db1,db2,db3"
binlog_format=row
default_storage_engine=InnoDB
innodb_autoinc_lock_mode=2
bind-address=0.0.0.0
wsrep_cluster_name="galera_cluster"
wsrep_node_address="db3"

sudo systemctl restart mariadb

$ MariaDB [(none)]> show status like 'wsrep_%';
+------------------------------+--------------------------------------+
| Variable_name | Value |
+------------------------------+--------------------------------------+
| wsrep_apply_oooe | 0.000000 |
| wsrep_apply_oool | 0.000000 |
| wsrep_apply_window | 0.000000 |
| wsrep_causal_reads | 0 |
| wsrep_cert_deps_distance | 0.000000 |
| wsrep_cert_index_size | 0 |
| wsrep_cert_interval | 0.000000 |
| wsrep_cluster_conf_id | 3 |
| wsrep_cluster_size | 3 |
| wsrep_cluster_state_uuid | 0f6dbe29-bec4-11e9-a243-eb8c0dc70c76 |
| wsrep_cluster_status | Primary |
| wsrep_cluster_weight | 3 |
| wsrep_commit_oooe | 0.000000 |
| wsrep_commit_oool | 0.000000 |
| wsrep_commit_window | 0.000000 |
| wsrep_connected | ON |
| wsrep_desync_count | 0 |
| wsrep_evs_delayed | |
| wsrep_evs_evict_list | |
| wsrep_evs_repl_latency | 0/0/0/0/0 |
| wsrep_evs_state | OPERATIONAL |
| wsrep_flow_control_paused | 0.000000 |
| wsrep_flow_control_paused_ns | 0 |
| wsrep_flow_control_recv | 0 |
| wsrep_flow_control_sent | 0 |
| wsrep_gcomm_uuid | 0f6d51e5-bec4-11e9-bd50-52974fa5f2b4 |
| wsrep_incoming_addresses | db1:3306,db2:3306,db3:3306 |
| wsrep_last_committed | 0 |
| wsrep_local_bf_aborts | 0 |
| wsrep_local_cached_downto | 18446744073709551615 |
| wsrep_local_cert_failures | 0 |
| wsrep_local_commits | 0 |
| wsrep_local_index | 0 |
| wsrep_local_recv_queue | 0 |
| wsrep_local_recv_queue_avg | 0.100000 |
| wsrep_local_recv_queue_max | 2 |
| wsrep_local_recv_queue_min | 0 |
| wsrep_local_replays | 0 |
| wsrep_local_send_queue | 0 |
| wsrep_local_send_queue_avg | 0.000000 |
| wsrep_local_send_queue_max | 1 |
| wsrep_local_send_queue_min | 0 |
| wsrep_local_state | 4 |
| wsrep_local_state_comment | Synced |
| wsrep_local_state_uuid | 0f6dbe29-bec4-11e9-a243-eb8c0dc70c76 |
| wsrep_open_connections | 0 |
| wsrep_open_transactions | 0 |
| wsrep_protocol_version | 9 |
| wsrep_provider_name | Galera |
| wsrep_provider_vendor | Codership Oy <[email protected]> |
| wsrep_provider_version | 3.25(rddf9876) |
| wsrep_ready | ON |
| wsrep_received | 10 |
| wsrep_received_bytes | 790 |
| wsrep_repl_data_bytes | 0 |
| wsrep_repl_keys | 0 |
| wsrep_repl_keys_bytes | 0 |
| wsrep_repl_other_bytes | 0 |
| wsrep_replicated | 0 |
| wsrep_replicated_bytes | 0 |
| wsrep_thread_count | 2 |
+------------------------------+--------------------------------------+
61 rows in set (0.002 sec)
